ASTM A516 Gr.70 Pressure Vessel Carbon Steel Plate
Home > Products > Pressure Vessel > ASTM A516 Gr.70 Pressure Vessel Carbon Steel Plate

ASTM A516 Gr.70 Pressure Vessel Carbon Steel Plate


  • ASTM A516 Gr.70 Pressure Vessel Carbon Steel Plate
  • ASTM A516 Gr.70 Pressure Vessel Carbon Steel Plate
  • ASTM A516 Gr.70 Pressure Vessel Carbon Steel Plate
  • ASTM A516 Gr.70 Pressure Vessel Carbon Steel Plate

ASTM A516 Gr.70 Pressure Vessel Carbon Steel Plate

    Unit Price: 650 USD
    Min. Order: 1 Ton
    Packaging: Standard export packaging
    Productivity: 5000 TONS/MONTH
    Brand: HuiTong
    Transportation: Ocean,Land,Air,Express,Others
    Place of Origin: CHINA
    Supply Ability: 5000 TONS/MONTH
    HS Code: 7208512000
    Port: TIANJIN,QINGDAO,SHANGHAI

Basic Info

Model No.: ASTM A516 Gr 70

Product Description

Pressure Vessel steel plate covers carbon steel plate and alloy steel grades plate, which are designed for use in making pressure vessels, boilers, heat exchangers and any other vessels and tanks that to store liquid or gas at high pressures. It includes applications like below or similar: Crude Oil Storage Tanks.Pressure Vessel Steel Plate.


Standard: Pressure Vessel Steel Plate
Standard: A202, A203, A204, A285, A299, A302, A387, A515, A516, A517, A533, A537, A612, A662, EN10028-2, EN10028-3, EN10028-5, EN10028-6, JIS G3103, JIS G3115, GB713, GB3531, DIN 17155
Pressure vessel steel plate is used for many applications where the pressure inside is significantly higher than atmospheric pressure.


A537 cl1 Steel Plate a537 steel Plate ASTM A537 Class 2 Plate ASTM A537 Class 2 Pressure Vessel Steel Plate

A516 Availabillity
Grade Thickness Width Length
Grade 55/60/65/70 3/16" – 6" 48" – 120 " 96" – 480"

ASTM A516 Grade 70(A516GR70)
Grade Chemical Composition(%)
C Mn≥ Si P S
ASTM A516 Grade 70(A516GR70) 0.27-0.31 0.79-1.3 0.13-0.45 0.035 0.035
Grade Mechanical Property
Tensile Strength(MPa) Yield Strength(MPa) % Elongation in 2 in.(50mm) min Impacting Test Temperature(°C)
ASTM A516 Grade 70(A516GR70) 485-620 260 17 -20,40,-60
ASTM A516 Grade 65(A516GR65)
Grade Chemical Composition(%)
C Mn≥ Si P S
ASTM A516 Grade 65(A516GR65) 0.24-0.29 0.79-1.3 0.13-0.45 0.035 0.035
Grade Mechanical Property
Tensile Strength(MPa) Yield Strength(MPa) % Elongation in 2 in.(50mm) min Impacting Test Temperature(°C)
ASTM A516 Grade 65(A516GR65) 450-585 240 19 -20,40,-60
ASTM A516 Grade 60(A516GR60)
Grade Chemical Composition(%)
C Mn≥ Si P S
ASTM A516 Grade 60(A516GR60) 0.21-0.27 0.13-0.45 0.79-1.30 0.035 0.035
Grade Mechanical Property
Tensile Strength(MPa) Yield Strength(MPa) % Elongation in 2 in.(50mm) min Impacting Test Temperature(°C)
ASTM A516 Grade 60(A516GR60) 415-550 220 21 -20,40,-60
ASTM A516 Grade 55(A516GR55)
Grade Chemical Composition(%)
C Mn≥ Si P S
ASTM A516 Grade 55(A516GR55) 0.18-0.26 0.55-1.3 0.13-0.45 0.035 0.035
Grade Mechanical Property
Tensile Strength(MPa) Yield Strength(MPa) % Elongation in 2 in.(50mm) min Impacting Test Temperature(°C)
ASTM A516 Grade 55(A516GR55) 380-515 205 23 -20,40,-60

Pressure Vessel Steel Plate Applications:

  • A516 steel plate is carbon steel with specifications for pressure vessel plates and moderate or lower temperature service.
  • A537 is heat-treated and as a consequence, displays greater yield and tensile strength than the more standard A516 grades.
  • A612 is used for moderate and lower temperature pressure vessel applications.
  • A285 steel plates are intended for fusion-welded pressure vessels and plates are typically supplied in the as-rolled conditions.
  • TC128-grade B has been normalized and used in pressurized railroad tank cars.


We also offer Wear Resistant Steel Plate Nm450 Abrasion Steel Plate,If you need 2mm 5mm 6mm 10mm 20mm ASTM A36 Mild Ship Building Hot Rolled Carbon Steel Plate Price Please leave me a message,Weather Resistant Sheet Hot Rolled A588 A242 Corten Steel Plate.
